Wika
| Pangalan ng tatak | Blueway |
| Kulay | Kulay abo o puti |
| Cop | 4.0 ~ 4.5 |
| Paglabas ng Fan | Patayo o pahalang |
| Materyal | Galvanized na pulbos na bakal na pinahiran/plastik/hindi kinakalawang na asero |
| Max/rate ng temperatura | 28 ℃/40 ℃ |
| Lugar ng Pinagmulan | Guangdong China |
| Uri ng mga produkto | Swim Pool Heat Pump |
| Nagpapalamig | R410A |
| Application | Home, Villa, Spa, School, Hotel, Ospital |
| Mga keyword ng produkto | Swim Pool Heat Pump, Chiller Water Cooled, Industrial Water Chiller |
| Modelo | SPCH-I-1.0S | SPCH-I-3.0S | SPCH-I-4.0S | SPCH-i-5.0s | Spch-i-6.0s | SPCH-I-5S | SPCH-I-6S | SPCH-I-7S | SPCH-I-10S | SPCH-I-15S | SPCH-i-200t | |||
| HP | 2 | 3 | 4 | 5 | 6 | 5 | 6 | 7 | 10 | 15 | 25 | |||
| Power Supply | V/Hz/pH | 220-240/50/1, 208-230/60/1 | 380-415/50/3, 208-230/60/3, 380-415/60/3 | |||||||||||
| Pagganap ng Pag -init | Pag -init (1): A26/19 ° C. W26/28 ° C. |
Kapasidad ng pag -init | Kw / h | 2.5 ~ 9 | 3.0 ~ 12 | 4.0 ~ 17 | 5.0 ~ 20 | 6.0 ~ 24 | 5.0 ~ 20 | 6.0 ~ 24 | 7 ~ 28 | 9 ~ 38.5 | 12 ~ 59 | 24 ~ 116 |
| Pagkonsumo ng kuryente | KW | 0.2 ~ 1.65 | 0.24 ~ 2.22 | 0.33 ~ 3.2 | 0.42 ~ 4.15 | 0.51 ~ 5 | 0.42 ~ 4.1 | 0.5 ~ 4.95 | 0.58 ~ 5.5 | 0.75 ~ 8 | 1 ~ 12 | 2 ~ 23 | ||
| Cop | w/w | 12.5 ~ 5.45 | 12.5 ~ 5.4 | 12.1 ~ 5.31 | 11.9 ~ 4.82 | 11.76 ~ 4.8 | 12 ~ 4.9 | 11.9 ~ 4.86 | 12.1 ~ 5.1 | 12 ~ 4.81 | 12 ~ 4.92 | 12 ~ 5.04 | ||
| Pag -init (2): A15/12 ° C. W26/28 ° C. |
Kapasidad ng pag -init | Kw / h | 1.8 ~ 7.5 | 2.2 ~ 9.5 | 3 ~ 12.5 | 4 ~ 15.5 | 5 ~ 20 | 4 ~ 15.5 | 5 ~ 20 | 6 ~ 23.5 | 8 ~ 31 | 10 ~ 48 | 20 ~ 93.5 | |
| Pagkonsumo ng kuryente | KW | 0.27 ~ 1.7 | 0.33 ~ 2.1 | 0.48 ~ 3 | 0.66 ~ 4 | 0.81 ~ 4.94 | 0.65 ~ 3.92 | 0.81 ~ 5 | 0.95 ~ 5.75 | 1.31 ~ 7.9 | 1.65 ~ 12.5 | 3.4 ~ 24 | ||
| Cop | w/w | 6.7 ~ 4.4 | 6.67 ~ 4.52 | 6.25 ~ 4.17 | 6.06 ~ 3.88 | 6.17 ~ 4.05 | 6.15 ~ 3.95 | 6.2 ~ 4 | 6.32 ~ 4.1 | 6.11 ~ 3.92 | 6.06 ~ 3.84 | 5.88 ~ 3.9 | ||
| Pagganap ng paglamig | Paglamig: A35/24 ° C. W30/28 ° C. |
Kapasidad ng paglamig | Kw / h | 2 ~ 5.5 | 3 ~ 7.5 | 5 ~ 10.5 | 7 ~ 12.5 | 7.5 ~ 14 | 7 ~ 12.5 | 7.5 ~ 14 | 8 ~ 17 | 15 ~ 25 | 18 ~ 38 | 36 ~ 72 |
| Pagkonsumo ng kuryente | KW | 0.42 ~ 1.7 | 0.61 ~ 2.25 | 1 ~ 3.2 | 1.37 ~ 3.85 | 1.4 ~ 4.23 | 1.35 ~ 3.9 | 1.37 ~ 4.3 | 1.4 ~ 5 | 2.7 ~ 7.35 | 3.2 ~ 11.2 | 6.55 ~ 21.5 | ||
| Eer | w/w | 4.76 ~ 3.24 | 4.92 ~ 3.33 | 5 ~ 3.28 | 5.1 ~ 3.25 | 5.36 ~ 3.31 | 5.19 ~ 3.2 | 5.47 ~ 3.25 | 5.7 ~ 3.4 | 5.56 ~ 3.5 | 5.63 ~ 3.39 | 5.5 ~ 3.35 | ||
| Nakapaligid na temp. saklaw | ° C. | -7 ~ 46 | ||||||||||||
| Na -rate/max.outlet water temp. | ° C. | 28/40 | ||||||||||||
| Na -rate na rate ng daloy ng tubig | m³/h | 3.8 | 5.2 | 7.3 | 8.6 | 10.3 | 8.6 | 10.3 | 12 | 16.6 | 25.4 | 50 | ||
| Rated pressure drop | KPA | 4 | 5 | 5 | 7 | 13 | 7 | 13 | 15 | 15 | 17 | 23 | ||
| Controller | - | Micro processor based digital wire controller na may LCD display | ||||||||||||
| Panlabas na Gabinete | - | Galvanized na bakal na may patong na pulbos | ||||||||||||
| Tagapiga | I -type | - | Rotaty | Mag -scroll | ||||||||||
| Qty. | Nos. | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 2 | ||
| Nagpapalamig | - | R32/R410A | ||||||||||||
| Water Heat Exchanger | - | Titanium tube sa PVC shell | ||||||||||||
| Koneksyon ng tubig | Inlet at Outlet | pulgada | TN40 | TN40 | TN40 | TN40 | DN50 | TN40 | DN50 | DN50 | DN65 | DN65 | DN80 | |
| Tunog presyon sa 1m | DB (A) | 40 ~ 51 | 42 ~ 52 | 44 ~ 53 | 45 ~ 56 | 46 ~ 58 | 45 ~ 56 | 46 ~ 58 | 45 ~ 59 | 48 ~ 62 | 49 ~ 63 | 62 ~ 72 | ||
| Paglabas ng hangin | - | Paglabas ng gilid | Nangungunang paglabas | |||||||||||
| Dimensyon ng net | W*d*h | mm | 950*380*610 | 950*380*610 | 1110*430*700 | 1100*430*800 | 1100*430*960 | 1100*430*800 | 1100*430*960 | 1050*400*1260 | 1100*480*1480 | 1400*525*1630 | 2000*950*2100 | |
| Net weight | kg | 43 | 45 | 54 | 70 | 90 | ||||||||
Mga katangian na partikular sa industriya
| Imbakan / Tankless | Imbakan |
| I -type | Heat pump water heaters |
| Application | Komersyal, hotel, sambahayan, panlabas |
| Mapagkukunan ng kuryente | Elektriko |
| Kinokontrol ng app | Oo |
Iba pang mga katangian
| Boltahe (v) | 220 |
| Pagkatapos ng Serbisyo ng Serbisyo na ibinigay | Serbisyo sa Pagpapanatili at Pag -aayos ng Patlang |
| Warranty | 1 taon |
| Kapasidad | 0 |
| Pag -install | Freestanding |
| Pribadong amag | Hindi |
| logo/pattern | Silk screen printing, laser printing, hot stamping, inkjet printing, UV printing, heat-transfer printing, 3D printing |
| Lugar ng Pinagmulan | Guangdong, China |
| Pangalan ng tatak | Blueway |
| Numero ng modelo | SPCH2.5S |
| Materyal sa pabahay | Pinahiran ng galvanized na pulbos na bakal |
| Pangalan ng tatak | Blueway |
| Kulay | Kulay abo o puti |
| Cop | 4.0 ~ 4.5 |
| Paglabas ng Fan | Patayo o pahalang |
| Materyal | Galvanized na pulbos na bakal na pinahiran/plastik/hindi kinakalawang na asero |
| Max/rate ng temperatura | 28 ℃/40 ℃ |
| Lugar ng Pinagmulan | Guangdong China |
| Uri ng mga produkto | Swim Pool Heat Pump |
| Nagpapalamig | R410A |
| Application | Home, Villa, Spa, School, Hotel, Ospital |
Packaging at paghahatid
| Pagbebenta ng mga yunit: | Solong item |
| Solong laki ng pakete: | 145x145x145 cm |
| Single gross weight: | 68.000 kg |
